Artex C406-1 ELT Complete System | Blade Antenna
Artex C406-1 ELT Complete System | Blade Antenna - Image 2
Artex C406-1 ELT Complete System | Blade Antenna - Image 3
Artex C406-1 ELT Complete System | Blade Antenna - Image 4
Artex C406-1 ELT Complete System | Blade Antenna - Image 5
Artex C406-1 ELT Complete System | Blade Antenna - Image 6

Artex C406-1 ELT Complete System | Blade Antenna

Available within 30 days

11712,00 €14171,52 € Excl. VATIncl. VAT

Artex

The Artex C406-1 ELT was designed to meet the rigorous requirements of TSO C126 and to pass the toughest safety tests. In the event of a crash, the Artex C406 ELT will automatically transmit a 406 MHz digital message to a worldwide network of satellites, allowing first responders to quickly and accurately identify the incident location, reducing the search and rescue response time.

Condition Factory New
Certification FAA 8130 or EASA Form 1
Warranty 24 Months
Part Number: 455-5015 Category:

Available within 30 days

Add to wishlist

Shipping Methods

We ship with trusted carriers at our negotiated rates

  • Pick up from our store (LKHS Airport)

Convenient Pickup at LKHS – Whether You Arrive by Car or Plane

Description

Artex C406-1 ELT Complete System Features

  • Operates on 121.5, 243, and 406 MHz frequencies
  • Worldwide coverage
  • RF output
  • Rod, whip, and blade antenna compatible
  • Compatible with an aircraft navigation system with an optional interface
  • Automatic or manual activation
  • 5-year lithium battery
  • Self-tests: G-Switch Enabled, 406 MHz Power Antenna/Coax Connection, Position Data Present, and Low Battery

The complete system kit – PN 455-5015 – includes:

  • C406-1 ELT
  • Lithium battery
  • Install kit (455-7421)
  • Mounting tray (452-5050)
  • Top cover (452-3052)
  • Mounting cap (452-5052)
  • Buzzer (130-4004)
  • Remote Switch/Install kit (455-6196)
  • Tri-band blade antenna (110-340)
  • Coax cable

Specification

Technical Overview

CertificationsTSO C126 ETSO 2C126 Cospas/Sarsat Approved Transport & Industry Canada Approved
Operating Frequencies406 MHz, 121.5 MHz, 243 MHz ±0.005% (A3X)
Ouput Power406 MHz: 5 W +/- 2 dB (520 ms / 50 sec) for 24 hours @ -20°C, 121.5/243.0 MHz: 100 mW minimum (+20 dBm) for 50 hours @ -20°C
Output ConnectorBNC Female (121.5/243.0/406 MHz)
ActivationAutomatic by 4.5 feet per second (2.3 G) Primary G-Switch or Manual Activation
Battery5 year Lithium (LiMnO2, solid cathode), Replacement Battery Part No. 452-0133
Certified TemperaturesOperating: -20°C to +55°C, Storage: -55°C to +85°C
Self TestsG-Switch Enabled, 406 MHz Power, Antenna/Coax Connection, Position Data Present, Low Battery
